🔔 Assessment 3

Classroom

• Github Classroom

What should be delivered?

• Folder: Entrega_3_FPGA_NIOS_IP
• Video of the project working with an explanation (approx. 1.5 min)

In this delivery, we will encapsulate the peripheral we created to control the stepper motor (Entrega-1) in Platform Designer (creating a memory-mapped peripheral) so that we have a dedicated component to control the motor.

Hardware

The diagram below is an overview of what needs to be done. In this concept, we will "encapsulate" the IP developed in Entrega-1 into a "memory-mapped peripheral" (StepMotor-MM). For this, it will be necessary to add extra logic, usually called Glue Logic, which interfaces between the bus and the IP.

Glue Logic

The control logic must interface with the Stepper Motor peripheral on all control signals (except the outputs (phase)), in order to abstract the memory-mapped access for the peripheral. The easiest way to do this is to assign functionalities to peripheral addresses, for example:

Offset	Functionality	Type
0	EN	R/W
1	DIR	R/W
2	VEL	R/W
...	...

The table above maps each address of the peripheral to a different functionality. In this example, if the user wants to activate the motor, they must write to address 0 of this peripheral.

Note that some addresses are Read Only and others are Read/Write (type). This is because it doesn't make sense (nor is it physically possible) to write to some addresses.

(rubric C) Software

Submission - google forms

In addition to the HW part, we will develop a C library that will abstract the interface with this peripheral. The peripheral must have a driver capable of interacting with it. We will standardize some functions to define a standard interface:

// For rubric C
int motor_init( ..... );        // Initializes the peripheral
int motor_halt( ..... );        // Deactivates the peripheral
int motor_en( ..... );          // Returns if there was any click

(rubric A/B) Software (improving)

Add the following functions (each one + half a concept):

// For rubric B/A
int motor_dir( ..... );      // sets direction
int motor_vel( ..... );      // sets speed

This driver should be distributed in two files: motor.c and motor.h. This driver should be distributed in two files: motor.c and motor.h.
